Avtron 8100 Container Load Bank
ISO containerized resistive load bank with capacities up to 2850kW
resistive
Available
CapacityUp to 2850 kW
Voltage400V/480V, 3-phase
Frequency50/60 Hz
CoolingForced air with vertical discharge
Key Features
- ISO containerized design for outdoor installation
- SIGMA 2 control system for precise load management
- Vertical hot air discharge for safe operation
- Walk-in control room for convenient operation
- High-quality stainless steel resistive elements
- Comprehensive safety features including thermal protection
- Internal lighting and power outlets for maintenance
- Anti-condensation heaters in control cabinets
Technical Specifications
| Standard Capacity | Up to 2850 kW |
| Load Step Resolution | 1 kW |
| Voltage Rating | 400V @ 50Hz (2500 kW), 480V @ 60Hz (2850 kW) |
| Control System | SIGMA 2 Control |
| Hot Air Discharge | Vertical |
| Construction | 10ft ISO style container with carbon steel structure |
| Cooling System | Forced-air cooling by axial metal-bladed aerofoil fans |
| Fan Quantity | Two fans |
| Resistor Elements | Non-finned sheathed stainless steel elements |
| Element Rating | Continuously rated to operate at up to 800°C |
| Load Tolerance | Within 2½% of total capacity |
| Ambient Temperature | Rated at 35°C (50°C rating available) |
| Humidity | Up to 90% RH, non-condensing |
| Cable Entry | 450 × 280mm side access point with additional 610 × 213mm plate under floor |
Physical Specifications
| Dimensions (L×W×H) | 3000 × 2440 × 2590 mm |
| Weight | Approx. 5000 kg |
| Cooling | Forced air with vertical discharge |
| Noise Level | 85 dB(A) at 3m |
| Protection Rating | IP54 (control enclosures) |
